The same 206 Ah LFP cell in a power grade: 1C continuous and 6C pulse, for high-rate duty cycles.
02Overview
Product · Technical data
LFP Prismatic Cell 206 Ah, Power
The same 206 Ah LFP cell in a power grade: 1C continuous and 6C pulse, for high-rate duty cycles.
Model-specific price, datasheet and lead time. Engineering reply within one business day.
Specification
Brochure data
- Battery type
- LFP (lithium iron phosphate, prismatic aluminium shell)
- Model
- CBA54173204-206Ah
- Nominal voltage
- 3.2 V
- Nominal capacity
- 206 Ah
- Rated current
- 1C (206 A)
- Dimensions
- 54 × 173 × 204 mm (T × W × H)
Preliminary figures from the current brochure. Final configuration and performance are confirmed in the quotation.
03Key features
-
Configuration attributes
- Available configurations include: 206 Ah, LFP, High rate.
-
Specified against the duty cycle
- Cell and plate selection matched to the real operating profile.
- Capacity and autonomy sized to the load, not to a catalogue average.
-
Batch control
- Incoming material control and in-process inspection on every batch.
- Traceability from plate casting through to packing.
-
End-of-line testing
- Electrical testing before packing, with results available on request.
04Specification
| Parameter | Value |
|---|---|
| Battery type | LFP (lithium iron phosphate, prismatic aluminium shell) |
| Model | CBA54173204-206Ah |
| Nominal voltage | 3.2 V |
| Nominal capacity | 206 Ah |
| Rated current | 1C (206 A) |
| Dimensions | 54 × 173 × 204 mm (T × W × H) |
| Weight | 4000 g ±120 g |
| Maximum charging voltage | 3.65 V |
| Minimum discharge voltage | 2.5 V |
| Maximum pulse discharge current | 6C (10 s, ≥30% SOC, 25 ±2 °C) |
| Maximum pulse charge current | 6C (10 s, ≤80% SOC, 25 ±2 °C) |
| Energy density, mass | ≥ 165 Wh/kg |
| Energy density, volume | ≥ 350 Wh/L |
| AC internal resistance | < 0.3 mΩ (fresh cell) |
| Monthly self-discharge | ≤ 3.5% per month |
| Rest SOC | ≥ 5% SOC |
| Operating altitude | ≤ 2000 m |
| Company certification | ISO 9001 · ISO 14001 · ISO 45001 |
Figures are taken from the current AllGrand product brochure. Specifications are indicative and may be revised without notice — confirm with our engineers before ordering.
Applications & selection
Confirm cell format, electrical limits and system integration
Typical fit
- Commercial battery modules and packs
- Energy-storage system integration
- High-power and long-duration battery designs
Confirm before quotation
- Required energy, power and usable voltage window
- Continuous and peak C-rate
- BMS, thermal design and mechanical constraints
Engineering guides
Battery storage RFQ checklist Use the same technical inputs our engineers need to price and configure a system. Commercial BESS sizing checks Turn load data, usable energy, C-rate and site constraints into a defensible specification. Supplier due diligence questions Compare scope, interfaces, test evidence, guarantees and service assumptions.
Send the load and installation details for a model-specific answer.
Our engineering team normally replies within one business day.
